Osisense XMLR – The Easy Switch for Machine Pressure Control
Are you looking for an easy solution to control machine pressure? Telemecanique Sensors has the answer: OsiSense XMLR, the intuitive pressure switch that combines high performance and maximum ease of use.
Easy to mount
Minimize installation time and effort. Mounting is easy and flexible with the compact-sized, rotating body and reversed display function.
- Compact size
- Rotating body
- Reversed display
Easy to set up
The ergonomic design of OsiSense XMLR sets the new standard for configuration ease. Use two simple pushbuttons to navigate an intuitive menu structured according to the VDMA standards.
- Intuitive menu basedon VDMA standards
- Navigation by two pushbuttons
Easy to maintain
At each device start up, all segments of the display briefly light up to confirm that it is operating correctly. If necessary, the device status can be further tested via an additional fast diagnostic function.
- Tested at startup
- Fast diagnostics
- 12 pressure range sizes: -1 to 600 bar
- Display pressure unit: Bar, PSI, kPa, MPa
- Fluid entry: G1/4A female, 1/4″-18NPT female, 7/16-20UNF-2B female.
- Power supply: 24 V DC
- Electrical connection: M12, 4 or 5 pin
- Digital output: PNP or NPN
- Analog ouput: 4…20 mA or 0…10 V
- Overall accuracy: <=1% of measuring range
- Degree of protection: IP65 and IP67
- Operating temperature range: -20…+80°C
- Certification: cULus based on UL 61010-1
Contact us today to find out more!
